QuickBOLT's mounts are the best in the industry and continue to improve the daily job of solar installation. Use the Roof Type filter below to quickly filter the Quick Catalog. Or shop by category via the main menu.
A PDF cheat sheet of our best selling mounts.
A PDF guide to the complete product line.
| Product | Test Results Averages | Certifications | Resources | |
|---|---|---|---|---|
● Asphalt TPO EPDM
|
17662
QB2 with Microflashing - Silver
Multi Roof Mount - QB2 Kit with 3" Microflashing and Stainless Steel L-Foot. |
• 1,418 lb Uplift
• 475 lb Lateral
|
•Miami-Dade Approval•TAS 100(A)-95•ASTM E331•ASTM E2140•ASTM D7147•UL2703 Recognized Component | |
● Asphalt TPO EPDM
|
17663
QB2 with Microflashing - Silver
Multi Roof Mount - QB2 Kit with 4" Microflashing and Stainless Steel L-Foot |
• 1,418 lb Uplift
• 475 lb Lateral
|
•Miami-Dade Approval•TAS 100(A)-95•ASTM E331•ASTM E2140•ASTM D7147•UL2703 Recognized Component | |
● Asphalt TPO EPDM
|
17862
QB2 with Microflashing - Black
Multi Roof Mount - QB2 Kit with 3" Microflashing and Stainless Steel Low Profile Black L-Foot |
• 1,418 lb Uplift
• 475 lb Lateral
|
•Miami-Dade Approval•TAS 100(A)-95•ASTM E331•ASTM E2140•ASTM D7147•UL2703 Recognized Component | |
● Asphalt TPO EPDM
|
17863
QB2 with Microflashing - Black
Multi Roof Mount - QB2 Kit with 4" Microflashing and Stainless Steel Low Profile Black L-Foot |
• 1,418 lb Uplift
• 475 lb Lateral
|
•UL2703 Recognized Component•Miami-Dade Approval•TAS 100(A)-95•ASTM D7147•ASTM E2140•ASTM E331 | |
● Asphalt TPO EPDM
|
17962
QB2 with Microflashing - Black Split Top
Multi Roof Mount - QB2 Kit with 3" Microflashing and Stainless Steel Low Profile Black Split Top L-Foot |
• 752 lb Uplift
• 438 lb Lateral
|
•Miami-Dade Approval•TAS 100(A)-95•ASTM E331•ASTM E2140•UL2703 Recognized Component | |
● Asphalt TPO EPDM
|
17963
QB2 with Microflashing - Black Split Top
Multi Roof Mount - QB2 Kit with 4" Microflashing and Stainless Steel Low Profile Black Split Top L-Foot |
• 752 lb Uplift
• 438 lb Lateral
|
•Miami-Dade Approval•TAS 100(A)-95•ASTM E331•ASTM E2140•UL2703 Recognized Component | |
● Asphalt TPO EPDM
|
16319
Butyl Bottom Deck Mount Kit - Silver
Deck Mount Kit - Silver |
• 1,310 lb Uplift
• 460 lb Lateral
|
•UL2703 Recognized Component•Miami-Dade Approval•TAS 100(A)-95•ASTM D7147 | |
● Asphalt TPO EPDM
|
16320
Butyl Bottom Deck Mount Kit - Black
Deck Mount Kit - Black |
• 1,310 lb Uplift
• 460 lb Lateral
|
•UL2703 Recognized Component•Miami-Dade Approval•TAS 100(A)-95•ASTM D7147 | |
● Asphalt Shingle
|
17782
QuickPATCH™ -
The QuickPATCH™ is a Patent Pending Roof Patch designed to patch holes on the roof. The product uses butyl on the bottom to seal the hole, the flashing ads rigidity and the butyl on the top will hold the shingle in place. Each QuickPATCH is individually shrink-wrapped for protection. 4"x5" Galvanized Steel with 0.5mm Butyl Seal - 150/CS |
|||
● Asphalt Shingle
|
16323
Conduit Puck™ Kit -
2-1/4" EPDM Conduit Mount with 3/4" Clip+Screw 60/CS |
•TAS 100(A)-95 | ||
● Asphalt Shingle
|
16321
Conduit Puck™ -
EPDM Cylinder Conduit Mount w/Screw |
•TAS 100(A)-95 | ||
● Metal
|
17766
QB RibRider ® -
Adjustable Solar Mount 90/180 combo 75mm Butyl base 32/CS. Perfect for Exposed Fastener, Trapezoidal, and Ribbed metal roofs. Use low torque to walk in the screw to avoid stripping. |
• 1,510 lb Uplift
|
•ASTM D7147•UL2703 Recognized Component | |
● Metal
|
17747
The Throne - Set Screw 15MM Standing Seam Mount -
Standing Seam Metal Mount S/S |
• 1,103 lb Uplift
• 790 lb Lateral
|
•UL2703 Recognized Component | |
● Stone Coated Steel
|
17752
Non-Adjustable Hook for Side Mount Rails -
SCS Straight 90 No-Batten Kit Hook with 5/16" x 3" screws 304 |
• 1,689 lb Uplift
• 3,109 lb Lateral
|
•UL2703 Recognized Component | |
● Stone Coated Steel
|
17640
All Stone Coated Steel Hook with Wide Base, 12.5mm Height Adjust -
90° All SC-Steel Hooks, 12.5mm Height Adjust Range, Wide Base Kit with 5/16" X 3" Solar Screws |
• 818 lb Uplift
• 1,622 lb Compression |
•UL2703 Recognized Component | |
● Stone Coated Steel
|
17630
Non-Adjustable Hook for Side Mount Rails -
90° Non-Adjustable Stone Coated Steel Roof Hook "No Batten" Kit with 5/16" X 3" Screws |
• 1,243 lb Uplift
|
•UL2703 Recognized Component | |
● Stone Coated Steel
|
17624
Non-Adjustable Hook for Side Mount Rails - Short -
90° (Short) Non-Adjustable Stone Coated Steel Roof Hook 76mm Batten Bridge Kit with 5/16" X 3" Screws |
• 1,617 lb Uplift
• 152 lb Compression |
•UL2703 Recognized Component | |
● Stone Coated Steel
|
17612
Height Adjustable 18mm for Side Mount Rails - Short -
90° Stone Coated Steel Roof Hook, 18mm Height Adjust Range Kit with 5/16" X 3" Screws |
• 816 lb Uplift
• 243 lb Lateral
• 303 lb Compression |
•Miami-Dade Approval•ASTM D7147•UL2703 Recognized Component | |
● Flat Tile
|
17734
Bracket for Tile Hooks -
Conduit Bracket for Tile |
|||
● Flat Tile
|
17608
Flat Tile Roof Hook for Side Mount Rails -
90° Flat Tile Roof Hook, 38mm Height Kit with 5/16" X 3" Screws. Type 304 Stainless Steel |
• 203 lb Uplift
• 141 lb Compression |
•UL2703 Recognized Component | |
● Flat Tile
|
17542
Flat Tile Roof Hook for Side Mount Rails -
90° Flat Tile Roof Hook, 38mm Height Kit with 1/4" X 3" Screws. Type 304 Stainless Steel |
• 203 lb Uplift
• 141 lb Compression |
•UL2703 Recognized Component | |
| ● Curved Tile
|
17734
Bracket for Tile Hooks -
Conduit Bracket for Tile |
|||
● Curved Tile
|
17510
Non-Adjustable Hook for Side Mount Rails -
90° Non-Adjustable Curved Tile Roof Hook Kit with 1/4" X 3" Screws. Type 304 Stainless Steel |
• 1,336 lb Uplift
• 230 lb Compression |
•UL2703 Recognized Component•ASTM D7147 | |
● All Tile
|
17598
Height Adjustable All Tile Roof Hook for Side Mount Rails -
All-Tile ADJB 2XB 90 1/4" X 3" Kit 10H-20S/KTC. Type 304 Stainless Steel |
• 2,434 lb Uplift
• 306 lb Compression |
•UL2703 Recognized Component | |
| ● All Tile
|
17734
Bracket for Tile Hooks -
Conduit Bracket for Tile |
|||
● All Tile
|
15890
Flashing for Curved Tile Hooks -
GalvA Flashing for use with Wide Based Roof Hooks |
|||
● All Tile
|
17589
Height Adjustable All Tile Roof Hook for Side Mount Rails -
90° All Tile Roof Hook, 8mm Height Adjust Range Kit with 1/4" X 3" Screws - for Curved & Flat Tile Roofs - works with or without battens. Type 304 Stainless Steel |
• 2,091 lb Uplift
• 487 lb Lateral
• 395 lb Compression |
•UL2703 Recognized Component | |
● All Tile
|
17587
Height Adjustable All Tile Roof Hook for Side Mount Rails -
90° All Tile Roof Hook, 8mm Height Adjust Range Kit with 5/16" X 3" Screws - for Curved & Flat Tile Roofs - works with or without battens. Type 304 Stainless Steel |
• 2,091 lb Uplift
• 487 lb Lateral
• 395 lb Compression |
•UL2703 Recognized Component |
